❑ Core i3/i5 11th generation CPU provide powerful performance
❑ All aluminium alloy shell, Fanless design for silent operation
❑ Dual HDMI Port, supports duplicate or extend mode
❑ Various interfaces meet the needs of different scenarios
❑ Core i3/i5 11th generation CPU provide powerful performance
❑ All aluminium alloy shell, Fanless design for silent operation
❑ Dual HDMI Port, supports duplicate or extend mode
❑ Various interfaces meet the needs of different scenarios
MODEL |
HK600U |
| Processor | Intel Tiger Lake UP3 CPU : Core i3 11th generation Optional : Core i5 11th generation |
| Operating System | Windows 10 / Windows 11 / Linux |
| Memory | 1*SO-DIMM DDR4 3200MHz 8GB, up to 16GB |
| Storage | M.2 SSD 128GB, up to 512GB |
| Power Supply | 24V 120W (need use Power USB Ports) 24V 90W (no usage of Power USB Ports) |
| I/O Ports | Serial Port: 3*DB9 COM Ports 1*RJ48 COM Ports 2*COM ports can be set voltageUSB: 2*USB 3.0 TYPE A 2*USB 2.0 TYPE A 3*12V Power USB 1*24V Power USB LAN: Cash Drawer: Audio: Power-in: Video: Power-Out: Button: |
| Optional features | Wireless: Dual-band Wi-Fi® 802.11a/b/g/n/ac 2.4GHz/5GHz BT5.0 Bracket: Rail Bracket on both side (for wall mount/desk mount) Cable: Power Cable for Monitors |
| Operating Voltage | 100V~240V |
| Casing Material | High-quality aluminum alloy / sandblasted oxidation |
| Environment | Operating: -10ºC – 60ºC / 5%-95% RH non-condensing Storage: -20ºC – 85ºC / 5%-95% RH non-condensing |
| EMC and Safety | CE / FCC |
| Colour | Silver-Gray |
