❑ 11th generation Intel CPU provides powerful performance
❑ Integrated structural design, easy to use, fast and convenient
❑ Large roll design to reduce the number of exchange of paper
❑ Built-in high reliability of the IPC: 15-inch high-definition LCD screen, high-
sensitivity Capacitive touch
❑ Equipped with advanced security weighing module, which can effectively
help customers for loss prevention
❑ 11th generation Intel CPU provides powerful performance
❑ Integrated structural design, easy to use, fast and convenient
❑ Large roll design to reduce the number of exchange of paper
❑ Built-in high reliability of the IPC: 15-inch high-definition LCD screen, high-
sensitivity Capacitive touch
❑ Equipped with advanced security weighing module, which can effectively
help customers for loss prevention
❑ Optional Alarm light
❑ Optional scanner holder
❑ Optional Shelving tray
❑ Optional EFTPOS bracket
❑ Optional Alarm light
❑ Optional scanner holder
❑ Optional Shelving tray
❑ Optional EFTPOS bracket
❑ Optional Handheld scanner
❑ Optional 60Kg scale
❑ Optional 120Kg scale
| MODEL | HS610U |
| Processor | Intel Tiger Lake UP3 CPU : Core i3 11th generation Optional : Core i5 11th generation |
| Operating System | Windows 10 / Windows 11 / Linux |
| Memory | SO-DIMM DDR4 3200MHz 4GB, up to 16GB |
| Storage | 2.5inch SATA SSD 128GB, up to 512GB M.2 SSD 128GB, up to 512GB |
| Display Panel | 15” TFT LCD Display / 4:3 / Resolution : 1024*768 |
| Touch Screen | True flat capacitive touch screen |
| Power Supply | 150W integrated power supply |
| Integrated Scanner | Short type scanner, Supports 1D/2D Barcodes (Standard) |
| Integrated Printer | Middle type scanner, Supports Scales’ function (optional) 80mm thermal printer |
| Speaker | 2*3W Speaker |
| Wireless connection | Dual-band Wi-Fi® 802.11a/b/g/n/ac 2.4GHz/5GHz BT5.0 Optional |
| I/O Ports | 10*USB ports (1 of them only provide power, no USB signal) 6*Serial ports 1*RJ45 10/100/1000M Gigabit LAN port 1*HDMI Port 1*3.5mm Audio Port 1*MIC-IN 1*12V DC-IN 2*12V DC-OUT |
| Dimensions (LxWxH) | 360*560*1883mm (Without scale) |
| Weight | 62kg (Host + Base cabinet), 36kg (60kg Scale) |
| Optional Peripherals | Alarm light: Alarm light Number plate: Number plate Card reader: 3 tracks MSR (single MSR), MSR+RFID (multi-function card reader) Receipts collector: Waste receipt collector Fingerprint reader: Fingerprint reader Handheld scanner: External handheld scanner Cash module: Null Shelving tray: Shelving tray (left side and right side) Brackets: EFTPOS bracket, External handheld scanner bracket, External Printer Bracket Scale: Range: 60Kg, Range: 120Kg, Size: 450*600 (mm), Size: 800*600 (mm) Scale Back plate Plastic Bag hanger |
| Operating Voltage | 100 ~ 264VAC |
| Temperatures | Operating: 10ºC – 40ºC / 30%-75% RH non-condensing Storage: -5ºC – 50ºC / 30%-80% RH non-condensing |
| EMC and Safety | CE / FCC / RoHS Pending |
| Colour | Black |
